2024 Case TV450B Skid Steer
Machine Information
Make
Case IH
Model
TV450B Skid Steer
Model Year
2024
Details
Case TV450B Compact Track Loader Specs: High Flow Hydraulic - High Speed Transmission up to 8 mph - New Easy Track System - LED Lights Features: Platinum Cab option, hydraulic coupler, 2-speed drive, high-flow hydraulics option, ride control, self-leveling, low ground pressure, biodiesel-friendly. Engine: FPT F5B FL413 D*C001, Diesel, 4-cylinder, Tier 4 Final, 90 HP (67 kW) gross, 84 HP (62.6 kW) net, 207 cu in. (3.4 L) displacement, 282 ft-lb (383 Nm) peak torque. Operating Capacity: 4,500 lbs (2,045 kg) at 50% tipping load, 3,150 lbs (1,428.8 kg) at 35% tipping load. Tipping Load: 9,000 lbs (4,082.3 kg). Operating Weight: 10,610 lbs (4,808.1 kg). Lift Design: Vertical. Breakout Force: Lift 7,700 lbs (3,492.7 kg), Tilt 9,200 lbs (4,173 kg). Hydraulic System: 39.5 GPM (149.5 LPM) optional high-flow, 3,046 psi (210 bar) relief pressure. Travel Speed: 8.0 mph (12.9 km/h) high speed. Ground Pressure: 4.6 psi (31.7 kPa). Dimensions: Height to Bucket Hinge Pin: 131.6 in. (334.3 cm). Overall Length: 144.6 in. (367.3 cm) with bucket. Width: 76.0 in. (193.0 cm). Dump Height: 101.9 in. (258.8 cm). Dump Reach: 35.5 in. (90.2 cm). Ground Clearance: 9.5 in. (24.1 cm). Track Width: 17.7 in. (45.0 cm). Fuel Tank Capacity: 25.5 gal (96.5 L). Cycle Times: Raise Lift Arms 5.1 sec, Lower Lift Arms 3.2 sec, Bucket Rollback 2.0 sec, Bucket Dump 2.7 sec.
Location
Lebanon, Kansas, USA, 66952
Stock Number
AW44DLGM
Serial Number/VIN
JAFTV450ARM458131
New/Used
Used
Total Hours
111
Category
Skid Steers
Sub-Category
Track
Seller type
PRIVATE
Key Detail 1
111 Eng Hrs
Key Detail 2
1 Owner
Key Detail 3
Stored Inside
Warranty information
Warranty Information
UPDATE THIS SECTION
$68,000
